Model |
KX-E2 |
KX-E4 |
|
Max.
Print
Lines |
Up to 2
Lines |
Up to 4 Lines |
|
Max. No.
of
Print
Characters |
1 Line: 240
Characters
2 Lines: 120
Characters |
1 Line:
240 2 Lines:
120
3 Lines:
80 4 Lines:
60 |
|
Dot
Matrix
(Hor.
x
Vert.) |
1~2 lines:
5x5, 5x8 or 5x7,
7x10, or 9x7,9x8
1 Line:
12x16 |
1~4 Lines:
5x5,5x8 or 5x7
1~3 Lines:
5x5, 5x8 or 5x7, 7x10 or 9x7
9x8
1~2 Lines:
12x16 1 Line:18x24,24x32 |
|
Character
Height |
2~8 mm |
2~10mm |
|
Display
&
Input
Device |
Display:
Liquid Crystal Touch Panel(10.4 inch, Color), Back-Lit
Input Device:
Touch Panel, Input sound provided |
|
Max.
Print
Rate |
Up to 2,296
Characters/sec (Font 5x5, space 1 dot 1 Line) |
|
Standard
Characters |
Alphanumeric
(A-Z, a-z, 0-9), General Symbols (27 Characters ),
Space : 90
Characters |
|
Japanese
Characters |
Katakana,
Characters for Expiry Date : 24 Characters
(Font 7x10 and 5x8) |
|
Custom
Characters |
Each Dot
Matrix 128 Characters |
|
Functions |
Bar Codes
(Code 39 , ITF, NW-7), Data Storage (130 Data), Passwords
Dot mixture,
Calendar, Basic Counting, Speed Follow Up,
Reciprocating
printing,
etc. |
|
Input
Signal |
Print Object
detection, Printing Stop, Reciprocating printing,
Rotary
Encoder
Pulse |
|
Output
Signal |
Print Ready,
Abnormality, Alarm, Print in progress or Print End |
|
Data
Interface |
RS-232c at
baud rates selectable up to 19.2 kbps |
|
Print
Head
Cable
Length |
4
m |
|
Cabinet |
Stainless
Steel |
|
Power
Supply |
AC
100-120/220-240 ±10%
50/60
Hz 150
VA |
|
Operating
Temperature
Range |
0-40oC |
|
Humidity
Range |
30-90% r.h.
(no condensing) |
|
Size(WxDxH) |
360 x 330 x
490 |
|
Approx.
Weight |
25 kg |
